Moving Coil Controller VLC-25

Features

• Brushed (1-phase) and brushless (3-phase) axis operations
• 2x STO inputs and 1x STO output
• Servo position feedback
• Incremental encoder with index
• Output (standard) with PWM (Space-Vector_Modulated) at 48 VDC Max
• Serial interface RS-232 Non-isolated, 9600 baud standard, selectable between 2400-460800
• Protective measures Reverse polarity of power supply
• Programme space Macro memory: 53983 bytes
• Maximum number of macros: 256
• Maximum number of programme registers: 2048

VLC-25-07 (standard): 6 A DC, peak current 7.8 A
Replaces the product LAC-25.

VLC-25-13 (optional): 10 A DC, peak current 13 A
